The Solar Pole Star Light (20W–60W) is a cutting-edge, eco-friendly outdoor lighting solution designed to bring sustainable brilliance to your surroundings. Powered entirely by solar energy, this intelligent light automatically charges during the day and illuminates at night, offering a blend of beauty, efficiency, and durability.
| LED Rated Power | 20W LED | 30W LED | 40W LED | 45W LED | 60W LED |
|---|---|---|---|---|---|
| Type of Luminary | Post Top / Steet Light Type | ||||
| Power of PV module (W) Mono Perc | 200 Wp (50W x 4) | 300 Wp (75W x 4) | 400 Wp (100W x 4) | 400 Wp (100W x 4) | 520 Wp (130W x 4) |
| Lithium Battery Capacity (LifePO4) | 12.8V , 30AH | 12.8V , 36AH | 25.6V , 24AH | 25.6V , 30AH | 25.6V , 36AH |
| Typical Luminous Flux (Lm) | 3000 | 4500 | 6000 | 6750 | 9000 |
| Colour Temperature (CCT) | 4000K - 6500K | ||||
| Recommended Installation Height (Mtr.) | 4 Mtr. | 5 Mtr. | 6 Mtr. | 6 Mtr. | 6 Mtr. |
| Lenses Type | Diffuser / Lenses with Glass | Diffuser / Lenses with Glass | Diffuser / Lenses with Glass | Diffuser / Lenses with Glass | Diffuser / Lenses with Glass |
| Pole Material | 100% Aluminium Fixture | 100% Aluminium Fixture | 100% Aluminium Fixture | 100% Aluminium Fixture | 100% Aluminium Fixture |
| Backup | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* |
| No Load Current | Less than 20 Amp | Less than 20 Amp | Less than 20 Amp | Less than 20 Amp | Less than 20 Amp |
| Charge Controller | MPPT | MPPT | MPPT | MPPT | MPPT |
| Driver Efficiency | > 92% | > 92% | > 92% | > 92% | > 92% |
| Ingress Protection | IP65 | IP65 | IP65 | IP65 | IP65 |
| Dimensions of Inner Pakcing Box | ∅ 78 MM | ∅ 65 MM | ∅ 66 MM | ∅ 65 MM | ∅ 66 MM |
| Lighting mode | Light will glow in 100 % Brightness for first 4 Hrs & then , it will dim to 50% Brightness for balance 8 Hrs. | ||||
| Protection | Battery Deep Discharge , Over charge Protection , Open Load Protection , Reverse Current Flow Protection , Short Circuit Protection and Temperature Compensation. | ||||
| Packing | Pallet Packing -1 in 1 | ||||
| Gross Weight of Product (Kg) | 46 Kg | ||||
| Optional Features | Remote Monitoring System / Hybrid / CCTV Camera / Bluetooth | ||||
