The Semi-Integrated Model Newlite Solar Street Light (9W–50W) is a two-piece system in which the LED luminaire and solar panel are mounted adjacently on the pole.This configuration allows the solar panel to be tilted independently from the light fixture, ensuring optimal orientation toward the sun—a feature especially valuable in diverse conditions across India.
The luminaire is designed with an inbuilt battery and high-efficiency LEDs, while the solar panel remains separate for flexible positioning. This combination creates a versatile and multipurpose structure, delivering reliable performance, enhanced energy capture, and superior illumination for outdoor applications.
| LED Rated Power | 9W LED | 12W LED | 15W LED | 20W LED | 24W LED | 30W LED | 36W LED | 40W LED | 50W LED |
|---|---|---|---|---|---|---|---|---|---|
| Power of PV Module (W) -1 Day Autonomy | 40 Wp | 50 Wp | 50 Wp | 75 Wp | 75 Wp | 100 Wp | 100 Wp | 120 Wp | 165 Wp |
| Lithium Battery Capacity (Lifepo4) | 12.8V , 12AH | 12.8V , 12AH | 12.8V , 18AH | 12.8V , 24AH | 12.8V , 24AH | 12.8V , 30AH | 12.8 , 36AH | 12.8V , 42AH | 12.8 , 48AH |
| Power of PV Module (W) - 2 Days Autonomy | 60 Wp | 60 Wp | 60 Wp | 100 Wp | 100 Wp | 120 Wp | 150 Wp | 165 Wp | NA |
| Lithium Battery Capacity (LifePO4) | 12.8V , 18AH | 12.8V , 24AH | 12.8V , 30AH | 12.8V , 42AH | 12.8V , 60AH | 12.8V , 60AH | 12.8V , 54AH | 12.8V , 60AH | NA |
| Typical Luminous Flux (Lm) | 1350 | 1800 | 2250 | 3000 | 3600 | 4500 | 5400 | 6000 | 7500 |
| Colour Temperature (CCT) | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K |
| Mounting Pole | Tubular Pole | Tubular Pole | Tubular Pole | Tubular Pole | Tubular Pole | Tubular Pole | Octagonal Pole | Octagonal Pole | Octagonal Pole |
| Recommended Installation Height (Mtr.) | 5 Mtr. | 5 Mtr. | 6 Mtr. | 6 Mtr. | 6 Mtr. | 6 Mtr. | 6 Mtr. | 7 Mtr. | 7 Mtr. |
| Installation Diameter | ∅64 MM | ∅64 MM | ∅64 MM | ∅64 MM | ∅64 MM | ∅64 MM | ∅64 MM | ∅64 MM | ∅64 MM |
| Charge Controller Type | MPPT | MPPT | MPPT | MPPT | MPPT | MPPT | MPPT | MPPT | MPPT |
| Lenses Type | Lenses | Lenses | Lenses | Lenses | Lenses | Lenses | Lenses | Lenses | Lenses |
| LED Driver Efficiency | > 92% | > 92% | > 92% | > 92% | > 92% | > 92% | > 92% | > 92% | > 92% |
| Ingress Protection | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 |
| No Load Current | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp |
| Backup | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* |
| Dimensions of Product (MM) | 415 X 205 X 95 MM | 415 X 205 X 95 MM | 415 X 205 X 95 MM | 415 X 205 X 95 MM | 415 X 205 X 95 MM | 415 X 205 X 95 MM | 415 X 205 X 160 MM | 415 X 205 X 160 MM | 415 X 205 X 160 MM |
| Dimensions of Pakcing Box | 440 X 215 X 100 MM | 440 X 215 X 100 MM | 440 X 215 X 100 MM | 440 X 215 X 100 MM | 440 X 215 X 100 MM | 440 X 215 X 100 MM | 440 X 215 X 150 MM | 440 X 215 X 150 MM | 440 X 215 X 150 MM |
| Dimensions of Master Box | 440 X 430 X 390 MM | 440 X 430 X 390 MM | 440 X 430 X 390 MM | 440 X 430 X 390 MM | 440 X 430 X 390 MM | 440 X 430 X 390 MM | 450 X 460 X 455 MM | 450 X 460 X 455 MM | 450 X 460 X 455 MM |
| Gross Weight of Product (Kg) | 4.84 Kg | 4.98 Kg | 4.89 Kg | 5.58 Kg | 6.18 Kg | 6.68 Kg | 7.88 Kg | 8.48 Kg | 7.28 Kg |
| Master Packing | 8 Nos 1 in Master Box | 8 Nos 1 in Master Box | 8 Nos 1 in Master Box | 8 Nos 1 in Master Box | 8 Nos 1 in Master Box | 8 Nos 1 in Master Box | 4 Nos 1 in Master Box | 4 Nos 1 in Master Box | 4 Nos 1 in Master Box |
| Weight - Master Packing | 38.72 Kg | 39.84 Kg | 39.12 Kg | 44.68 Kg | 49.68 Kg | 53.44 Kg | 31.52 Kg | 33.92 Kg | 29.12 Kg |
| Lighting Mode | Light Will Glow in 100% Brightanss For Firts 4Hrs & then,it Will dim to 50% Brightansss for Balance 8 Hrs. | ||||||||
| Protections | Battery Deep Discharge, Over charge Protection, Open Load Protection, Reverse Current Flow Protection, Short Circuit Protection and Temperature Compensation. | ||||||||
| Indication | Red LED Blink - Battery Low Green LED Blinking - Battery Charging Green LED Continuos Glow - Battery Full charge |
||||||||
| Optional Features | Remote Monitoring System (RMS) / CCTV Camera / PIR Sensor / Bluetooth / Hybrid | ||||||||
