Dolphin Solar Street Light (30W–40W LED) is a high-performance outdoor lighting solution, engineered with automatic dusk-to-dawn functionality and advanced MPPT technology for maximum efficiency.
Featuring IP67 protection, A-Grade LiFePO₄ battery, and a robust wind-resistant structure, it ensures long-lasting reliability in diverse climates.
Ideal for smart cities, highways, industrial zones, and international projects, this eco-friendly solar light delivers superior illumination with sustainable performance.
| LED Rated Power | 30W LED | 40W LED | 45W LED |
|---|---|---|---|
| Power of PV Module (W) Mono Perc | 75 Wp | 120 Wp | 120 Wp |
| Lithium Battery Capacity (Lifepo4) | 12.8V , 30AH | 12.8V , 42AH | 12.8V , 45AH |
| Typical Luminous Flux (Lm) | 4500 | 6000 | 6750 |
| Colour Temperature (CCT) | 5500K - 6500K | 5500K - 6500K | 5500K - 6500K |
| Mounting Pole | Tubular Pole | Tubular Pole | Tubular Pole |
| Recommended Installation Height (Mtr.) | 6 Mtr. | 6 Mtr. | 7 Mtr. |
| Charge Controller Type | MPPT | MPPT | MPPT |
| Lenses Type | Plain / Diffuser | Plain / Diffuser | Plain / Diffuser |
| Driver Efficiency | 92% | 92% | 92% |
| Ingress Protection | IP66 | IP66 | IP66 |
| No Load Current | Less than 20Amp | Less than 20Amp | Less than 20Amp |
| Backup | 12 Hrs* | 12 Hrs* | 12 Hrs* |
| Installation Diameter | ∅ 42 MM | ∅ 42 MM | ∅ 42 MM |
| Dimensions of Product (MM) | 371 X 130 X 70 MM | 371 X 130 X 70 MM | 371 X 130 X 70 MM |
| Dimensions of Master Box | 400 X 450 X 460 MM | 400 X 450 X 460 MM | 400 X 450 X 460 MM |
| Gross Weight of Product (Kg) | 1.280 Kg | 1.280 Kg | 1.280 Kg |
| Master Packing | 20 Nos 1 in Master Box | 20 Nos 1 in Master Box | 20 Nos 1 in Master Box |
| Weight - Master Packing | 27.70 Kg | 27.70 Kg | 27.70 Kg |
| Lighting Mode | Light will glow in 100 % Brightess for frist 4 Hrs & then , it will dim to 50% Brightess for balance 8 Hrs . | ||
| Protections | Battery Deep Discharge , Over charge Protection , Open Load Protection , Reverse Current Flow Protection , Short Circuit Protection and Temperature Compensation. | ||
| Indication | Red LED Blink - Battery Low Green LED Blinking - Battery Charging Green LED Continuos Glow - Battery Full Charge |
||
| Optional Features | Remote Monitoring Stsyem / CCTV Camera / Hybrid / Bluetooth | ||
